VLX 100 Pivot Door

VLX 100 Pivot Door in Fort Lauderdale, FL | Juniper Windows Fort Lauderdale

The VLX 100 Pivot Door is a full-height aluminum entry door that rotates on a vertical center axis instead of swinging on side hinges. It’s built for oversized openings and heavy glass panels, which makes it a favorite for modern waterfront homes, mid-century renovations, and new construction across Fort Lauderdale. We install this door as an authorized ViewLux installation partner, which means factory-trained crews, warranty-safe work, and measurements that account for South Florida’s wind and moisture realities. If you’re pricing a pivot door right now, call (754) 354-1396 and we’ll give you a written quote for the exact size and glass package you’re considering.

Call (754) 354-1396

Product Overview – VLX 100 Pivot Door

The VLX 100 is a heavy-duty aluminum pivot door that rotates on a vertical center axis, allowing oversized glass panels and a true architectural statement at the entry. Unlike a conventional hinged door that hangs from the side jamb, a pivot door carries its weight through a top and bottom pivot mechanism. That engineering difference is what lets the VLX 100 reach spans up to 60 inches wide and 120 inches tall while still operating smoothly with one hand.

We see these doors specified most often on Fort Lauderdale homes where the entry is the first thing a guest registers. Think Victoria Park modern builds, Rio Vista renovations with deep front setbacks, and the clean-lined new construction going up in the Coral Ridge and Lauderdale Harbors neighborhoods. Homeowners choose the VLX 100 because it reads as one clean plane of glass and aluminum, not a collection of stiles, rails, and panels. The door feels substantial without looking heavy.

The frame is extruded aluminum with a 0.098-inch wall thickness and a 2.56-inch profile width. That’s a meaningful amount of metal. It resists racking, holds its square under wind load, and gives the pivot hardware a rigid structure to work against. The result is a door that won’t sag, rub, or drift out of alignment the way thinner aluminum doors sometimes do after a few South Florida summers.

Technical Specifications

Here are the numbers that matter when you’re comparing the VLX 100 against other pivot door systems on the market.

All panels are fabricated to the opening, which means customization is built into the product rather than an upcharge. You pick the glass, the finish, the swing direction, and whether you want complementary sidelight panels to bookend the door.

Performance Features

Thermal Efficiency
The VLX 100 uses a thermal break that separates the interior and exterior aluminum faces, so heat doesn’t conduct straight through the frame. NFRC-rated energy performance means you can verify the numbers for your specific glass package. In Fort Lauderdale, where August humidity pushes AC systems hard, a thermally broken frame is the difference between a door that feels warm to the touch and one that doesn’t.

Acoustic Performance
A pivot door seals differently than a hinged door. There’s no continuous side hinge gap, and the perimeter gaskets compress evenly around all four edges. Combined with laminated or double-glazed glass, the VLX 100 reduces street noise, which matters if your entry faces Federal Highway, Sunrise Boulevard, or any busy Fort Lauderdale thoroughfare.

Airtightness & Weather Seal
The pivot system pulls the panel into the frame, which compresses the weatherstripping consistently around the full perimeter. On a hinged door, the top corner opposite the hinge is the classic leak point. A pivot door distributes compression evenly, so the seal holds. We install every unit with AAMA 812 low-expansion foam sealant on all perimeter joints, which fills micro-gaps that standard caulk won’t reach.

Waterproofing
Fort Lauderdale gets roughly 60 inches of rain a year, and a lot of it comes sideways during summer storms. The VLX 100 has a sill design built to shed water outward, and the bottom pivot hardware is sealed against standing water. Proper installation is what keeps water out long-term, which is why we follow AAMA 2400/2410 standards on every job and run a final water test before we call it done.

Wind Resistance
This door is wind-load rated for local climate requirements, and the laminated glass option adds impact-resistant performance for windborne debris protection. For homes in Fort Lauderdale’s coastal high-velocity wind zones, the VLX 100 can be configured to meet the same structural demands as any other opening in the building envelope.

Security & Hardware
A pivot door doesn’t rely on three small hinge screws to stay in the opening. The top and bottom pivot points are anchored into the frame and floor, which makes forced entry through the hinge side considerably harder than a standard in-swing door. The multi-point locking hardware, when specified, engages at the top, bottom, and latch side simultaneously.

Color & Glass Options

The VLX 100 comes in six finishes. Premium Black and Pure White are the two we order most in Fort Lauderdale. Black reads sharp against white stucco and light limestone, which covers a good portion of the newer builds in the city. White disappears into lighter facades and suits homes where the door should feel like part of the wall. Anodized Silver and Bronze both work well on mid-century homes and commercial storefronts where a metallic finish fits the architecture. Champagne is a warmer metallic that pairs well with coastal interiors and brass hardware. Teak Wood is a woodgrain powder coat, not real wood. It gives you the warmth of a timber door without the maintenance that actual teak demands in salt air and humidity.

For glass, Clear is the most popular for entry doors because it maximizes light transfer. Frosted and Obscure are the choice when you want privacy without losing brightness, which is common on front doors that face a street or a neighbor. Low-E is the energy play, reducing solar heat gain through the glass. Tempered is required in most door applications and is included as the base safety glass. Laminated is the impact-rated option and also improves acoustic performance.

Installation by Juniper Windows Fort Lauderdale in Fort Lauderdale

Installing a pivot door is not the same as setting a pre-hung entry door. The pivot hardware has to be set on a perfectly level slab, the frame has to be square within a tight tolerance, and the sealant work has to be exact. A door that’s out of level by a quarter inch will drift open or closed on its own, and no amount of hardware adjustment will fix a frame that wasn’t set square in the rough opening.

Our process starts with a pre-installation inspection of the opening. We check the slab for level, the rough opening for square, and we verify the structural header is sized for the door’s weight and wind load. Then we set the frame level, plumb, and square, shimming it until every measurement is within manufacturer tolerance. We apply AAMA 812 low-expansion foam sealant to the full perimeter, which creates an airtight and waterproof joint between the frame and the rough opening. The installation follows AAMA 2400/2410 standards from start to finish, and we run a final water test on the sill and side jambs before we call the job complete.

Improper installation voids the manufacturer warranty. That’s not a scare tactic, it’s the reality of how aluminum and glass door warranties are written. When you buy a ViewLux product installed by a partner company, the warranty stays intact because the work is done to the standard the manufacturer requires. We’ve been called out to Fort Lauderdale homes to inspect pivot doors installed by general contractors who didn’t understand the tolerances involved, and the fixes usually cost more than the original install would have.

Fort Lauderdale also has specific building code requirements for doors in windborne debris regions east of I-95 and on the barrier island. If your opening requires an impact-rated assembly, we’ll specify the right glass and hardware so the door passes inspection the first time.

Frequently Asked Questions – VLX 100 Pivot Door

What is the lead time for the VLX 100 Pivot Door?
Lead time is typically 8 to 12 weeks from final order confirmation because each panel is fabricated to the specific opening dimensions. We recommend starting the process at least 3 months before you want the door installed, especially if you’re coordinating with a larger renovation in Fort Lauderdale. Call (754) 354-1396 and we’ll confirm current production timelines.

Does the VLX 100 qualify for energy tax credits?
The door itself may qualify for an energy-efficient home improvement tax credit if it meets the IRS requirements in effect for the tax year it’s placed in service, and certain low-E and laminated glass packages will help it reach that threshold. The frame’s thermal break and NFRC ratings matter for the calculation. Ask your tax professional, and we can provide the NFRC documentation for the configuration you choose.

What warranty comes with the Pivot Door?
The product warranty covers the aluminum frame and finish against manufacturing defects, and the glass carries its own coverage. Your installation work performed by Juniper Windows Fort Lauderdale carries our workmanship warranty as well. The full warranty terms depend on the exact configuration, and we’ll outline them in writing before you place an order.

Can I customize the size of the VLX 100?
Yes. The VLX 100 is fabricated to your opening, not sold in stock sizes. Panels can be built up to 60 inches wide and 120 inches tall, and if your rough opening is smaller, the door is made to fit it exactly. There’s no cutting, shimming, or “making it work” – the door is produced for the dimensions we verify on site in Fort Lauderdale.

How do I maintain aluminum frames in Fort Lauderdale’s salt air?
Clean frames every three to four months with mild soap and water, and rinse thoroughly. Salt deposits, if left alone, can corrode powder coat finishes over time. Lubricate the pivot points annually with a dry silicone spray, and check the weatherstripping compression at the same interval. We’re happy to walk you through maintenance at installation, and we offer annual service checks for pivot doors we’ve installed.

Get a Quote – VLX 100 Pivot Door in Fort Lauderdale

A pivot door is a significant purchase, and you should know exactly what you’re getting before you commit. Call (754) 354-1396 to schedule a free on-site measurement and a written quote for your specific opening. We’ll bring finish samples and glass options to you, check your slab and rough opening, and give you a price that won’t change once work starts.

Written by the team at Juniper Windows Fort Lauderdale, authorized ViewLux installation partner serving Fort Lauderdale, FL.
